1756-L83ES Rockwell AB Control Logix 10 communication module.
1756-L83ES Rockwell AB Control Logix 10 communication module.1756 Series Model No: 1756-L83ES. The Allen-Bradley 1756-L83ES GuardLogix 5580 controller is part of the Bulletin 1756 series. The controller has a user memory of 10 megabytes and a safety memory of 5 megabytes. The unit has 128,000 total I/O (maximum) and it supports up to 250 nodes for EtherNet/IP network communication. The controller supports up to 31 standard tasks and 1 safety task. The 1756-L83ES controller has a built-in USB port (USB 2.0) and an embedded EtherNet port.
Description
PRODUCT INFORMATION OF 1756-L83ES Rockwell AB Control Logix 10 communication module.
| Brand | Allen-Bradley / Rockwell Automation |
| Series | ControlLogix |
| Part Number | 1756-L83ES |
| Supported EtherNet/IP nodes | 250 nodes max. |
| Safety communication options (standard/safety) | EtherNet/IP, ControlNet, DeviceNet |
| Controller tasks | 31 standard tasks/1 safety task |
| Supported number of programs per task | 1000 |
| User memory | 10 megabytes |
| Safety memory | 5 megabytes |
| Digital I/O / Analog I/O | 128,000 / 4000 max. |
| Built-in communication | 1 USB port (USB 2.0), embedded Ethernet port |
| Ethernet performance | 10/100/1000 megabits per second |
| Current draw at 1.2 Volts DC | 5.0 milli Amps |
| Current draw at 5.1 Volts DC | 1.2 Amps |
| Weight | 0,39 kilograms (0.868 pounds) |
