1769-IF4I American Rockwell AB 1769IF4I input module brand new original warranty for 1 year.
1769-IF4I American Rockwell AB 1769IF4I input module. 1769 Series Model No: 1769-IF4I. The Allen-Bradley 1769-IF4I is a Compact I/O analog input module with Four (4) isolated, differential input channels. This module is designed to interface field devices that sends 0-21 mA and +/- 10VDC analog signals. This module is compatible for use with a 1769 CompactLogix chassis or MicroLogix 1500.
Description
PRODUCT INFORMATION OF 1769-IF4I American Rockwell AB 1769IF4I input module.
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Brand | Allen-Bradley |
| Product Type: | Analog Input Module |
| Part Number/Catalog No. | 1769-IF4I |
| Product Line | CompactLogix |
| Module Type | Isolated Analog Input Module |
| No. of Inputs: | 4 Individually isolated Differential and single ended inputs |
| Input Type | Analog Input |
| Power Supply Distance rating: | 8 |
| Input current range: | 0-21 mA |
| Communication Cable | 4 Point |
| Current signal normal ranges: | 0-20mA; 4-20 mA |
| Shipping Weight | 2 lbs. |
| Shipping Dimensions | 8 x 8 x 5 in. |
| Current signal full range: | 0-21 mA; 3.2 – 21 mA. |
| Input / Output voltage range: | 0-10.5VDC |
| Replacement Terminal Block | 1769-RTBN18 |
| Converter Type | Sigma-Delta |
| Wire Type | Copper-90 degrees Celsius |
| Wire Size (Solid) | 22-14 AWG |
| Rated working voltage: | 30VAC; 30VDC |
| UPC | 10781180908634 |
| Channel Diagnostics: | Over- or under-range by bit reporting, process alarms |
| Slot width: | 1 |
| Recommended cable: | Belden™ 8761 (shielded) |
| Dimension: | 118 mm (height) x 87 mm (depth) x 35 mm (width) [52.5 mm (width) for 1769-IF8] Height including mounting tabs is 138 mm 4.65 in (height) x 3.43 in (depth) x 1.38 in (width) [2.07 in (width) for 1769-IF8] Height including mounting tabs is 5.43 in |
