1769-OW16 American Rockwell Automation AB new warranty 1 year 1769OW16.
1769-OW16 American Rockwell Automation AB new warranty 1 year 1769OW16. 1769 Series Model No: 1769-OW16. The 1769-OW16 is Compact I/O expansion module. This module has Sixteen (16) Relay output channels. This module is designed for an operating voltage range of 5 – 265VAC and 5 – 125V DC. module is compatible for use with MicroLogix 1500 and CompactLogix controllers.
Description
PRODUCT INFORMATION OF 1769-OW16 American Rockwell Automation AB new warranty 1 year 1769OW16.
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Brand | Allen-Bradley |
| Product Family: | Compact I/O |
| Part Number/Catalog No. | 1769-OW16 |
| Product Type: | Discrete Output Module |
| Product Line | CompactLogix |
| Module Type | Relay Output Module |
| No. of outputs: | Sixteen (16) |
| Operating Voltage | 5 to 265 Volts AC or 5 to 125 Volts DC |
| Enclosure Type | Open |
| No. of Groups: | 2 |
| No. of Channels per group: | 8 |
| Communication Cable | 16 Point |
| Outputs | 16 Normally Open (8 points/group) |
| Operating Temperature | 0 to 60 degrees Celsius |
| Compatible controllers: | MicroLogix 1500; CompactLogix controllers |
| Output Type: | AC/DC normally open relay |
| Series | A and B |
| Operating Voltage range: | 5 to 265V ac 5 to 125V dc |
| Shipping Weight | 2 pounds |
| Signal delay, On: | 10 ms |
| Shipping Dimensions | 8 x 8 x 5 inches |
| Wire Type | Copper-90 |
| Solid Wire Size | 22 to 14 AWG |
| Bus Current draw, 5.1 V: | 125 mA |
| Bus Current draw, 24 V: | 100 mA |
| Heat Dissipation: | 2.83 Watts |
| UPC | 10612598286239 |
| Slot width: | 1 |
| Stranded Wire Size | 22 to16 AWG |
| Current per Module | 20 Amps |
