| Width |
12.7 cm |
| Height |
12.95 cm |
| Depth |
13.58 cm |
| Approximate weight |
1.11 kg |
| Screw torque, ground terminal, maximum |
0.96 Nm |
| Screw torque, power and alarm terminals |
0.23 Nm |
| Number of ports 10/100 Mbps RJ45 |
12 |
| Number of combination-ports RJ45/Mini GBIC |
2 |
| Layer 2 |
No |
| Layer 3 |
No |
| Manageable |
Yes |
| Power over Ethernet |
802.3 af (PoE) |
| Number of ports PoE |
4 |
| Max. PoE power |
30 W |
| Power consumption, maximum |
30 W |
| Power dissipation |
30 W |
| Firmware type |
Full |
| Number of combination ports 10/100/1000 Mbps |
2 |
| Power consumption at 24V DC, 40 ˚C |
15 W |
| Total number of ports |
18 |
| Wire size, alarm connection, solid or stranded, UL/CSA-rated style 1007 or 1569 twisted-pair copper appliance wiring material (AWM) wire |
0.5 mm² |
| Wire size, DC power connection, solid or stranded copper wire rated at 75 °C or greater |
0.5 mm² |
| Wire size, ethernet connection |
RJ45 connector according to IEC 60603-7, 2 or 4-pair category 5e minimum cable according to TIA 568-B.1 or category 5 cable according to ISO/IEC 24702 |
| Mounting method |
DIN rail (top hat rail) |
| Ethernet |
Yes |
| Protection type |
Alarm not rated |
| Alarm relay at 30V DC |
1 A |
| Alarm relay at 48V DC |
0.5 A |
| CIP sync (IEEE 1588) |
Yes |
| DLR |
Yes |
| Ethernet data rate |
10/100 Mbps |
| Isolation voltage (continuous), basic insulation type, DC power ports to ground, and PoE power ports to ground |
60 V |
| Maximum insulation, DC power connection |
1.2 mm |
| Power input at 12 – 48V DC, class 2/SELV |
0.5 A |
| Power over Ethernet input power, DC |
48 V |
| Wire size, ground connection, stranded copper wire, minimum |
4 mm² |
| Wire strip length, alarm connection |
6.3±0.5 mm |
| Wire strip length, DC power connection |
6.3±0.5 mm |
| Wiring category on console and alarm ports |
3 |
| Wiring category on DC power ports |
2 |
| Wiring category on Ethernet ports |
2 |
