| Width |
8 cm |
| Height |
12.95 cm |
| Depth |
12.19 cm |
| Approximate weight |
1.22 kg |
| Screw torque, ground terminal, maximum |
0.4 Nm |
| Screw torque, power and alarm terminals |
0.23 Nm |
| Layer 2 |
No |
| Layer 3 |
No |
| Manageable |
Yes |
| Power consumption, maximum |
14 W |
| Power dissipation |
14 W |
| Firmware type |
Lite |
| Isolation voltage (continuous), basic insulation type, DC power ports to ground, DC power ports to ethernet ports, and DC power ports to alarm ports |
60 V |
| Number of ports 10/100 Mbps SFP |
4 |
| Number of ports 10/100/1000 Mbps SFP |
2 |
| Power consumption at 24V DC, 40 ˚C |
12.5 W |
| Total number of ports |
6 |
| Wire size, alarm connection, solid or stranded, UL/CSA-rated style 1007 or 1569 twisted-pair copper appliance wiring material (AWM) wire |
0.5 mm² |
| Wire size, DC power connection, solid or stranded copper wire rated at 75 °C or greater |
0.5 mm² |
| Mounting method |
DIN rail (top hat rail) |
| Ethernet |
Yes |
| Protection type |
Alarm not rated |
| Alarm relay at 30V DC |
1 A |
| Alarm relay at 48V DC |
0.5 A |
| Maximum insulation, DC power connection |
1.2 mm |
| Power input at 12 – 48V DC, class 2/SELV |
0.5 A |
| Wire size, ground connection, stranded copper wire, minimum |
4 mm² |
| Wire strip length, alarm connection |
6.3±0.5 mm |
| Wire strip length, DC power connection |
6.3±0.5 mm |
| Wiring category on console ports |
3 |
| Wiring category on DC power and alarm ports |
2 |
