| Width |
15.54 cm |
| Height |
16.45 cm |
| Depth |
14.67 cm |
| Approximate weight |
2.88 kg |
| Screw torque, alarm terminal |
0.23 Nm |
| Screw torque, ground terminal |
0.51 Nm |
| Screw torque, power terminal |
0.56 Nm |
| Number of combination-ports RJ45/Mini GBIC |
4 |
| Layer 2 |
Yes |
| Layer 3 |
No |
| Manageable |
Yes |
| Power dissipation |
42 W |
| Number of combination ports 10/100/1000 Mbps |
4 |
| Number of ports 10/100/1000 Mbps SFP |
8 |
| Power consumption at 24V DC, 40 ˚C |
42 W |
| Power input at 12 – 54V DC, maximum |
5 A |
| Total number of ports |
12 |
| Wire size, alarm connection, solid or stranded, UL/CSA-rated style 1007 or 1569 twisted-pair copper appliance wiring material (AWM) wire |
0.5 mm² |
| Wire size, ground connection, solid or stranded copper wire |
4 mm² |
| Mounting method |
DIN rail (top hat rail) |
| Ethernet |
Yes |
| Protection type |
Alarm not rated |
| Alarm relay at 30V DC |
1 A |
| Alarm relay at 48V DC |
0.5 A |
| CIP sync (IEEE 1588) |
Yes |
| DLR |
Yes |
| Isolation voltage (continuous), basic insulation type, all ports to ground |
60 V |
| NAT |
Yes |
| Wire size, DC power connection, solid or stranded copper wire rated at 30 ˚C, or greater, above the surrounding air temperature |
0.52 mm² |
| Wire strip length, alarm connection |
6.3±0.5 mm |
| Wire strip length, DC power connection |
6.3±0.5 mm |
| Wiring category on console ports |
3 |
| Wiring category on DC power and alarm ports |
2 |
| Wiring category on Ethernet ports |
2 |
