| Number of analogue inputs |
4 |
| Resolution of the analogue inputs |
12 Bit |
| Input, current |
Yes |
| Input, voltage |
Yes |
| Input, resistor |
No |
| Input, resistance thermometer |
No |
| Input, thermocouple |
No |
| Input signal, configurable |
No |
| Output, current |
No |
| Output, voltage |
No |
| Output signal configurable |
No |
| Analogue inputs configurable |
Yes |
| Analogue outputs configurable |
No |
| Type of electric connection |
Screw connection |
| Data range |
0 to 65535 |
| Channel to channel isolation |
Non-isolation |
| Update time |
180 ms per enabled channel |
| Input group to bus isolation |
No isolation |
| Module error |
Voltage: ±1.5% @ over full temperature range, -20…65°C (-4…149°F), Current: ±2.0% @ over full temperature range, -20…65°C (-4…149°F) |
| Wire size |
Solid: 0.14 mm2 (26 AWG)…1.5 mm2 (16 AWG) @ Rated @ 90 °C (194 °F) insulation maximum, Stranded: 0.14 mm2 (26 AWG)…1.0 mm2 (18 AWG) @ Rated @ 90 °C (194 °F) insulation maximum |
| Suitable for safety functions |
No |
| SIL according to IEC 61508 |
None |
| Recommended maximum shielded cable length |
10 m |
| Voltage ranges |
0 V |
| Current range |
0 mA |
| Field input calibration |
Not required |
| Overall accuracy |
Voltage terminal: ±1% full scale @ 25°C, Current terminal: ±1% full scale @ 25°C |
