| Number of HW-interfaces industrial Ethernet |
1 |
| Number of HW-interfaces RS-232 |
1 |
| Number of HW-interfaces RS-422 |
1 |
| Number of HW-interfaces RS-485 |
1 |
| Number of HW-interfaces USB |
1 |
| Number of password levels |
3 |
| Number of grey-scales/blue-scales of display |
0 |
| Number of system buttons |
0 |
| Voltage type of supply voltage |
DC |
| Number of function buttons, programmable |
0 |
| Number of online languages |
8 |
| Suitable for safety functions |
No |
| Supporting protocol for TCP/IP |
Yes |
| Supporting protocol for Modbus |
Yes |
| Supporting protocol for Data-Highway |
No |
| With colour display |
Yes |
| Number of pixels, vertical |
600 |
| With numeric keyboard |
Yes |
| With alpha numeric keyboard |
Yes |
| With message indication |
Yes |
| With message system (incl. buffer and confirmation) |
Yes |
| Process value representation (output) possible |
Yes |
| Process default value (input) possible |
Yes |
| With recipes |
Yes |
| With printer output |
Yes |
| Additional software components, loadable |
Yes |
| Supporting protocol for EtherNet/IP |
Yes |
| Screen diagonal |
10 inch |
| Number of pixels, horizontal |
800 |
| Useful project memory/user memory |
32000 MB |
| Supply voltage DC |
18 V |
| Touch technology |
Resistive touch |
| Operator input |
Analog touch |
| Power consumption |
14 W @ 24V DC, 0.48 A |
| Operating system |
WINCE 6.0 |
| Backlight |
Type: LED, Life: minimum 40000 hours |
| Software |
Connected Components Workbench software, release 8.0 and later |
| Input voltage |
18…32V DC (24V DC nominal) |
| Number of HW-interfaces serial TTY |
0 |
| Number of HW-interfaces parallel |
0 |
| Number of HW-interfaces other |
0 |
| Number of interfaces PROFINET |
0 |
| Number of HW-interfaces Wireless |
0 |
| Number of buttons with LED |
0 |
| Supporting protocol for LON |
No |
| Supporting protocol for ASI |
No |
| Supporting protocol for PROFIBUS |
No |
| Supporting protocol for CAN |
No |
| Supporting protocol for INTERBUS |
No |
| Supporting protocol for KNX |
No |
| Supporting protocol for DeviceNet |
No |
| Supporting protocol for SUCONET |
No |
| Supporting protocol for other bus systems |
No |
| Supporting protocol for SERCOS |
No |
| Supporting protocol for INTERBUS-Safety |
No |
| Radio standard Bluetooth |
No |
| Radio standard Wi-Fi 802.11 |
No |
| IO link master |
No |
| Supporting protocol for AS-Interface Safety at Work |
No |
| Supporting protocol for DeviceNet Safety |
No |
| Supporting protocol for Foundation Fieldbus |
No |
| Supporting protocol for PROFINET CBA |
No |
| Supporting protocol for PROFINET IO |
No |
| Supporting protocol for PROFIsafe |
No |
| Supporting protocol for SafetyBUS p |
No |
| Radio standard GPRS |
No |
| Radio standard GSM |
No |
| Radio standard UMTS |
No |
| With SW interfaces |
Yes |
| Type of display |
TFT |
| Number of colours of the display |
1.67E7 |
| Power supply |
24 V |
| North American temperature code |
T4A |
| Real-time clock |
Yes |
| CPU speed |
800 MHz |
| Flash memory (ROM), min |
256 MB |
| SDRAM (RAM), min |
256 MB |
| Recipe |
50 recipe files |
| Preferred controller |
Micro800, MicroLogix |
| Battery lifespan, min |
5 years @ 25 °C (77 °F) |
| External memory storage |
USB port and micro-SD (secure digital) card – industrial grade micro-SD cards recommended, supports SDSC and class 6 & class 10 SDHC micro-SD cards, FAT32/16 formats, up to 32 GB maximum size |
