ABB three-phase voltage monitor CM-PAS.31S/10102321.

PRODUCT INFORMATION OF ABB three-phase voltage monitor CM-PAS.31S/10102321.

General Information

• Extended Product Type:

  CM-PAS.31S

• Product ID:

  1SVR730774R1300

• EAN:

  4016779851794

• Catalog Description:

  CM-PAS.31S Three-phase monitoring relay 2c/o, 0,0.1-30s, L1-L2-L3=3×160-300VAC

• Long Description:

  The CM-PAS.31S relay is from the CM three-phase monitors range. This relay operates with a rated control supply voltage / three-phase measuring voltage of 160-300 V AC and has a 2 c/o output with contacts rated at 250 V / 4 A. The CM-PAS.31S monitors the phase parameters phase failure, phase sequence and phase unbalance. An ON-delay is adjustable over a range of instantaneous to 30 s (0, 0.1-30 s). A sealable transparent cover for protection against unauthorized changes is available as accessory. The device offers screw connection technology with double-chamber cage connection terminals.

Classifications

• Object Classification Code:

  B

• ETIM 4:

  EC001441 – Phase monitoring relay

• ETIM 5:

  EC001441 – Phase monitoring relay

• ETIM 6:

  EC001441 – Phase monitoring relay

• ETIM 7:

  EC001441 – Phase monitoring relay

• eClass:

  V11.0 : 27371803

• UNSPSC:

  39121536
