ATV312HU22N4 inverter, ATV312 series 2.2kW spot
ATV312HU22N4 inverter, ATV312 series 2.2kW spot Schneider Inverter Model Number: ATV312HU22N4
This Altivar 312 3-phase variable speed drive has a rated power of 2.2kW, 5.9kVA, and a 380V to 500V AC rated output voltage. It is suitable for industrial machines such as materials handling and packaging, packing, textile machines, special machines, pumps and fans.
It has a compact form-factor with 142mm width, allowing for a flexible and easy installation on a mounting plate. It also offers a snap-lock seal, status and faults display, a jog dial navigation button and an integrated EMC filter.
It offers high readability of key parameters thanks to a bright LED 4-digit display. SoMove software compatibility enables saving and transfering of configurations to spare drive, reducing maintenance downtime.
Description
PRODUCT INFORMATION OF SCHNEIDER ATV312HU22N4 inverter, ATV312 series 2.2kW spot
| Range of product | Altivar 312 |
|---|---|
| Product or component type | Variable speed drive |
| Product destination | Asynchronous motors |
| Product specific application | Simple machine |
| Assembly style | With heat sink |
| Component name | ATV312 |
| motor power kW | 2.2 kW |
| motor power hp | 3 hp |
| [Us] rated supply voltage | 380…500 V – 15…10 % |
| supply frequency | 50…60 Hz – 5…5 % |
| Network number of phases | 3 phases |
| line current | 8.9 A at 380 V, Isc = 5 kA 6.7 A at 500 V |
| EMC filter | Integrated |
| Apparent power | 5.9 kVA |
| maximum transient current | 8.3 A for 60 s |
| power dissipation in W | 79 W at nominal load |
| speed range | 1…50 |
| Asynchronous motor control profile | Sensorless flux vector control with PWM type motor control signal Factory set : constant torque |
| electrical connection | Al1, Al2, Al3, AOV, AOC, R1A, R1B, R1C, R2A, R2B, LI1…LI6 terminal 2.5 mm² AWG 14 L1, L2, L3, U, V, W, PA, PB, PA/+, PC/- terminal 5 mm² AWG 10 |
| supply of ATV312HU22N4 inverter | Internal supply for logic inputs: 19…30 V 100 mA, protection type: overload and short-circuit protection Internal supply for reference potentiometer (2.2 to 10 kOhm): 10…10.8 V 10 mA, protection type: overload and short-circuit protection |
| Communication port protocol | CANopen Modbus |
| IP degree of protection | IP20 on upper part without cover plate IP21 on connection terminals IP31 on upper part IP41 on upper part |
| option card of ATV312HU22N4 inverter | Communication card for CANopen daisy chain Communication card for DeviceNet Communication card for Fipio Communication card for Modbus TCP Communication card for Profibus DP |
| Supply voltage limits | 323…550 V |
| Prospective line Isc | 5 kA |
| continuous output current | 5.5 A at 4 kHz |
| Output frequency | 0…500 Hz |
| Nominal switching frequency | 4 kHz |
| switching frequency | 2…16 kHz adjustable |
| transient overtorque | 170…200 % of nominal motor torque |
| braking torque of ATV312HU22N4 inverter | 150 % during 60 s with braking resistor 100 % with braking resistor continuously 150 % without braking resistor |
| Regulation loop | Frequency PI regulator |
| Motor slip compensation | Automatic whatever the load Adjustable Suppressable |
| Output voltage | <= power supply voltage |
| tightening torque | Al1, Al2, Al3, AOV, AOC, R1A, R1B, R1C, R2A, R2B, LI1…LI6: 0.6 N.m L1, L2, L3, U, V, W, PA, PB, PA/+, PC/-: 1.2 N.m |
| Insulation of ATV312HU22N4 inverter | Electrical between power and control |
| Analogue input number | 3 |
| analogue input type | AI1 configurable voltage 0…10 V, input voltage 30 V max, impedance: 30000 Ohm AI2 configurable voltage +/- 10 V, input voltage 30 V max, impedance: 30000 Ohm AI3 configurable current 0…20 mA, impedance: 250 Ohm |
| sampling duration | AI1, AI2, AI3: 8 ms analog LI1…LI6: 4 ms discrete |
| response time of ATV312HU22N4 inverter | AOV, AOC 8 ms for analog R1A, R1B, R1C, R2A, R2B 8 ms for discrete |
| linearity error | +/- 0.2 % for output |
| Analogue output number | 1 |
| analogue output type | AOC configurable current: 0…20 mA, impedance: 800 Ohm, resolution: 8 bits AOV configurable voltage: 0…10 V, impedance: 470 Ohm, resolution: 8 bits |
| discrete input logic | Logic input not wired (LI1…LI4), < 13 V (state 1) Negative logic (source) (LI1…LI6), > 19 V (state 0) Positive logic (source) (LI1…LI6), < 5 V (state 0), > 11 V (state 1) |
| Discrete output number | 2 |
| discrete output type | Configurable relay logic: (R1A, R1B, R1C) 1 NO + 1 NC – 100000 cycles Configurable relay logic: (R2A, R2B) NC – 100000 cycles |
| minimum switching current | R1-R2 10 mA at 5 V DC |
| maximum switching current | R1-R2: 2 A at 250 V AC inductive load, cos phi = 0.4 and L/R = 7 ms R1-R2: 2 A at 30 V DC inductive load, cos phi = 0.4 and L/R = 7 ms R1-R2: 5 A at 250 V AC resistive load, cos phi = 1 and L/R = 0 ms R1-R2: 5 A at 30 V DC resistive load, cos phi = 1 and L/R = 0 ms |
| Discrete input number | 6 |
| discrete input type | (LI1…LI6) programmable at 24 V, 0…100 mA for PLC, impedance: 3500 Ohm |
| Acceleration and deceleration ramps | S, U or customized Linear adjustable separately from 0.1 to 999.9 s |
| Braking to standstill | By DC injection |
| protection type | Input phase breaks: drive Line supply overvoltage and undervoltage safety circuits: drive Line supply phase loss safety function, for three phases supply: drive Motor phase breaks: drive Overcurrent between output phases and earth (on power up only): drive Overheating protection: drive Short-circuit between motor phases: drive Thermal protection: motor |
| insulation resistance | >= 500 mOhm 500 V DC for 1 minute |
| local signalling of ATV312HU22N4 inverter | 1 LED (red) for drive voltage Four 7-segment display units for CANopen bus status |
| time constant | 5 ms for reference change |
| frequency resolution | Analog input: 0.1…100 Hz Display unit: 0.1 Hz |
| connector type | 1 RJ45 for Modbus/CANopen |
| Physical interface | RS485 multidrop serial link |
| Transmission frame | RTU |
| transmission rate | 10, 20, 50, 125, 250, 500 kbps or 1 Mbps for CANopen 4800, 9600 or 19200 bps for Modbus |
| number of addresses | 1…127 for CANopen 1…247 for Modbus |
| number of drive | 127 for CANopen 31 for Modbus |
| Marking of ATV312HU22N4 inverter | CE |
| Operating position | Vertical +/- 10 degree |
| Outer dimension | 402 x 239 x 192 mm 184 x 140 x 150 mm 215 x 185 x 158 mm |
| Height of ATV312HU22N4 inverter | 184 mm |
| Width of ATV312HU22N4 inverter | 142 mm |
| Depth of ATV312HU22N4 inverter | 152 mm |
| Product weight | 3.1 kg |
| dielectric strength | 2410 V DC between earth and power terminals 3400 V AC between control and power terminals |
| electromagnetic compatibility | 1.2/50 µs – 8/20 µs surge immunity test level 3 conforming to IEC 61000-4-5 Electrical fast transient/burst immunity test level 4 conforming to IEC 61000-4-4 Electrostatic discharge immunity test level 3 conforming to IEC 61000-4-2 Radiated radio-frequency electromagnetic field immunity test level 3 conforming to IEC 61000-4-3 |
| Standards of ATV312HU22N4 inverter | IEC 61800-3 IEC 61800-5-1 |
| Product certifications | GOST C-Tick DNV UL CSA NOM |
| Pollution degree of ATV312HU22N4 inverter | 2 |
| Protective treatment | TC |
| vibration resistance | 1 gn (f= 13…150 Hz) conforming to EN/IEC 60068-2-6 1.5 mm (f= 3…13 Hz) conforming to EN/IEC 60068-2-6 |
| shock resistance of ATV312HU22N4 inverter | 15 gn for 11 ms conforming to EN/IEC 60068-2-27 |
| relative humidity of ATV312HU22N4 inverter | 5…95 % without condensation conforming to IEC 60068-2-3 5…95 % without dripping water conforming to IEC 60068-2-3 |
| Ambient air temperature for storage | -25…70 °C |
| ambient air temperature for operation | -10…50 °C without derating (with protective cover on top of the drive) -10…60 °C with derating factor (without protective cover on top of the drive) |
| operating altitude | <= 1000 m without derating 1000…3000 m with current derating 1 % per 100 m |
