CYLINDER HEAD GASKET SET FOR CATERPILLAR C15, C16, 3406E | NEW #MCBC15093

Use the universal gasket set P016386
For specific 6NZ, MBN serial number range
C15 Engine Specifications:
Year: 1999-2007
Liter: 15.2
CID: 928
Cylinder: L 6
Bore/Stroke: 5.4000-5.4020″, 6.7320″
Firing Order: 1-5-3-6-2-4Tune-Up Specifications:
Intake Valve Lash: .015″
Exhaust Valve Lash: .030″

Caterpillar C16 Engine Specifications:
Year: –
Liter: 15.6
CID: 955
Cylinders: L 6
Bore/Stroke: 5.4984-5.5004″ 6.750″
Compression Ratio: –
Firing Order: 1-5-3-6-2-4

Tune-Up Specifications:
Oil Pressure At Idle: 14.5 Psi Minimum
Oil Pressure: 88 PSI Maximum
Intake Valve Lash: .012-.018″
Exhaust Valve Lash: .027-.033″ (.680-.840 MM)

3406Engine Specifications:
Year 1993-2005
VIN E
Liter 14.6
CID 893
Engine Code 3406E
Cylinder L 6
VLV/CYL
Bore/Stroke 5.400-5.402″ (137.16-137.211 MM)6.500″ (165.1 MM)
Compression Ratio: 14.5:1
Firing Order 1-5-3-6-2-4
Comments DIESEL 3406E TRUCK, OHC, 24 VALVE, 5DS-1LW

Tune-Up Specs:
Compression Ratio: 174.5:1
Firing Order: 1-5-3-6-2-4
Intake Valve Lash: .012-.018″ cold
Exhaust Valve Lash: .027-.033″ cold

Camshaft Specifications:
Camshaft Journal Diameter: 3.3398-3.3413″
Camshaft Gear Bolt Torque: 150-210 FT/LBS
Lobe Lift:
Intake: .3820″Exhaust: .3352″

Make: CATERPILLAR
Model: C15
Year; 1999-2007
Liter: 15.2
CID: 928
Engine Code: C15
Cylinder: L 6
Bore/Stroke: 5.4000-5.4020″ 6.7320″
Firing Order: 1-5-3-6-2-4

New Thickness/Measured At 4.7180-4.7303″
Minimum Thickness 4.7050″
Warp Spec. .005″ OVERALL
OHC Camshaft Bore Diameter 3.5813- 3.5829″
Comments ** CAUTION OVERSIZE CAM BEARINGS USE CATERPILLAR PART’S #2170751 +.010″ AND # 2170752 +.030″

Valve Collapse
Valve Information
Stem Diameter Intake: .3713-.3721�
Stem Diameter Exhaust: .3713-.3721�
Total Length Intake: 7.9350-7.9710″
Total Length Exhaust: 7.9370-7.9730″
Head Diameter Intake: 1.845-1.855″
Head Diameter Exhaust: 1.641-1.651″

Angle Intake: 29-29.5º
Angle Exhaust: 44-44.5º
Margin Intake: .108″ MIN
Margin Exhaust:.081″ MIN
Recession Intake: .087-.110″ V/REC
Recession Exhaust:.047-.071″ V/REC

C15 Engine Specifications:
Year: 1999-2007
Liter: 15.2
CID: 928
Cylinder: L 6
Bore/Stroke: 5.4000-5.4020″, 6.7320″
Firing Order: 1-5-3-6-2-4

Tune-Up Specifications:
Intake Valve Lash: .015″
Exhaust Valve Lash: .030″

Caterpillar C16 Engine Specifications:
Year: –
Liter: 15.6
CID: 955
Cylinders: L 6
Bore/Stroke: 5.4984-5.5004″ 6.750″
Compression Ratio: –
Firing Order: 1-5-3-6-2-4

Tune-Up Specifications:
Oil Pressure At Idle: 14.5 Psi Minimum
Oil Pressure: 88 PSI Maximum
Intake Valve Lash: .012-.018″
Exhaust Valve Lash: .027-.033″ (.680-.840 MM)

3406Engine Specifications:
Year 1993-2005
VIN E
Liter 14.6
CID 893
Engine Code 3406E
Cylinder L 6
VLV/CYL
Bore/Stroke 5.400-5.402″ (137.16-137.211 MM)6.500″ (165.1 MM)
Compression Ratio: 14.5:1
Firing Order 1-5-3-6-2-4
Comments DIESEL 3406E TRUCK, OHC, 24 VALVE, 5DS-1LW

Tune-Up Specs:
Compression Ratio: 174.5:1
Firing Order: 1-5-3-6-2-4
Intake Valve Lash: .012-.018″ cold
Exhaust Valve Lash: .027-.033″ cold

Camshaft Specifications:
Camshaft Journal Diameter: 3.3398-3.3413″
Camshaft Gear Bolt Torque: 150-210 FT/LBS
Lobe Lift:
Intake: .3820″Exhaust: .3352″

Guide Height Intake: 1.358-1.398″
Guide Height Exhaust: 1.358-1.398″

Valve Seat Information
Seat Width Intake: .079″ MIN
Seat Width Exhaust: .049″ MIN
Seat Angle Intake: 29.75-30.75º
Seat Angle Exhaust: 44.75-45.75º
Seat Outside Diameter Exhaust:1.6861-1.6871″
Seat Outside Diameter Intake: 1.8902-1.8912″
Seat Inside Diameter Exhaust: 1.4(more…)
