EZD250E4200N Schneider plastic case circuit breaker economical fixed type front wiring four-level power distribution switch EZD250E4200N

Schneider plastic case circuit breaker economical fixed type front wiring four-level power distribution switch EZD250E4200N EZD molded case circuit breaker Model Number:  EZD250E4200N The EZD250E4200N of the EZD series is a Class A Class 4 fixed molded case circuit breaker, which meets the requirements of IEC60947&GB14048 standards. The product has an isolation mark and the position of the operating handle can reliably indicate the position of the internal contacts. The maximum expected mechanical life of the product is 10,000 times and the electrical life is 5,000 times @440V&In. All terminals are equipped with overload and short circuit protection (except the neutral level), equipped with The rated current of the thermal magnetic release is 200A, and different electrical accessories and connection accessories can be selected according to different needs. The circuit breaker and auxiliary devices meet the requirements of 45°C and 95% relative humidity required by IEC60068-2-30. The bottom plate or guide rail can be selected according to actual needs to be installed in the switch cabinet and provide class II panel insulation from all internal lines and the highest IP54 protection level. The materials used in the product are all non-polluting materials that meet the requirements of ISO14001 standards and can be recycled.
