LC1D205M7C Schneider LC1D three-level AC contactor AC24 220V 380V.
Schneider LC1D three-level AC contactor LC1D205M7C AC24 220V 380V.LC1D AC Contactor Model No: LC1D205M7C. LC1D205M7C is a 3-level contactor of TeSysD series, suitable for controlling various types of motors at an ambient temperature below 60°C, the maximum operating altitude is 3000m without derating, and the maximum operating frequency is 2400 times/hour. The control coil provides an AC voltage of 220V 50 /60Hz is used to control the combination and separation of contactors. The front of the product provides IP20 protection to prevent direct contact with fingers. The product has passed CCC certification. Flexible and simple installation methods can be clamped on a 2X35mm rail or directly screwed on the bottom plate.
Description
PRODUCT INFORMATION OF SCHNEIDER LC1D three-level AC contactor LC1D205M7C AC24 220V 380V.
| Product Series of LC1D205M7C | TeSys Deca |
|---|---|
| Product Series | TeSys Deca |
| product type | Contactor |
| product short name | LC1D |
| Application field of contactor | Applied to AC loads with power factor greater than or equal to 0.95 Applied to non-inductive or slightly inductive loads, resistance furnaces |
| use category | AC- 3AC-1 |
| number of poles | 3P |
| Rated working voltage [Ue] | Power circuit: <= 1000 V AC 25…400 Hz Power circuit: <= 460 V DC |
| Rated operating current [Ie] | 275 A 40 °C) at <= 440 V AC AC-1 for power circuits 205 A 40 °C) at <= 440 V AC AC-3 for power circuits |
| [Uc] control circuit voltage | 230V AC 50/60Hz |
| Motor power (kW) | 100 kW at 1000 V AC 50/60 Hz (AC-3) 63 kW at 220/240 V AC 50/60 Hz (AC-3) 110 kW at 380/400 V AC 50/60 Hz (AC-3) 110 kW at 415 V AC 50/60 Hz (AC-3) 110 kW at 440 V AC 50/60 Hz (AC-3) 129 kW at 500 V AC 50/60 Hz (AC-3) 129 kW at 660/690 V AC 50/60 Hz (AC-3) |
| model of LC1D205M7C | LC1D |
| Loop contact type | 3 NO |
| protection cap | None |
| Conventional thermal current [Ith] | 275 A at <40 °C for power circuits |
| Rated short-time withstand current [Icw] | 1500 A at <40 °C – 10 s for power circuit 920 A at <40 °C – 30 s for power circuit 740 A at <40 °C – 1 min for power circuit 500 A at <40 °C – 3 minutes for power circuit 400 A at <40 °C – 10 minutes for power circuit |
| Fuses for use with relays | 200 A aM at <= 440 V for power circuits 315 A gG at <= 440 V for power circuits |
| average impedance | 0.33 mΩ – Ith 275 A 50 Hz for power circuits |
| Rated insulation voltage [Ui] | Power circuit: 1000 V conforming to IEC 60947-4-1 |
| Overvoltage category | III |
| pollution level | 3 |
| Rated impulse withstand voltage [Uimp] | 8 kV according to IEC 60947 |
| Mechanical life | 8 Mcycles |
| Electrical life | 0.55 Mcycles 275 A AC-1 Ue <= 440 V 1.1 Mcycles 170 A AC-3 Ue <= 440 V 1 Mcycles 118 A AC-3 Ue 660/690 V |
| Control loop characteristics | AC at 50/60 Hz |
| Control voltage limit | 0.35…0.55 Uc -5…55 °C release 50/60 Hz 0.85…1.15 Uc -5…55 °C run 50/60 Hz |
| (~50Hz pickup) power consumption (VA) | 805 VA 50 Hz 0.3 20 °C) 970 VA 60 Hz 0.3 20 °C) |
| (~50Hz hold) power consumption (VA) | 55 VA 50 Hz 0.3 20 °C) 66 VA 60 Hz 0.3 20 °C) |
| heat dissipation | 18…24W |
| action time | 20…35 ms close 130 ms break |
| operating frequency | 2400 cycles/h at <55 °C |
| Wiring capacity | Control circuit: Bolt fastening Cable selection: Flexible wire without wire terminal Control circuit: Bolt fastening Cable selection: Flexible wire with wire terminal Power circuit: Bus terminal Cable selection: Hard wire without wire terminal Busbar Cross-section: 25 x 3 mm Power circuit: Cable with lugs Cable selection: single-strand hard wire without wire terminal |
| Tightening torque | Power circuit: 18 Nm Via busbar terminals Power circuit: 18 Nm Via cable connector Control circuit: 1.2 Nm Via bolt fastening |
| Auxiliary contact type | Does not contain |
| installation method | Chassis mounting rail installation |
| standard | GB 14048.4 IEC 60947-4-1 |
| certified product | CCC CE |
| IP protection class | IP20 front panel with LA9F conforming to IEC 60529 |
| Protective measures | TH conforms to IEC 60068-2-30 |
| ambient air temperature | -40…60 °C operation 60…70 °C with derating -60…80 °C storage |
| working altitude | 3000 m None |
| Shock and vibration resistance | Shock resistance with contacts open (2 gn (5…300 Hz)) conforming to IEC 60068-2-6 Shock resistance for 11 ms with contacts closed (15 gn) conforming to IEC 60068-2-27 Shock resistance with contacts closed (5 gn (5…300 Hz)) conforming to IEC 60068-2-6 Shock resistance 11 ms contact opening (7 gn) conforming to IEC 60068-2-27 |
| high of LC1D205M7C | 174 mm |
| width of LC1D205M7C | 168.5 mm |
| depth of LC1D205M7C | 181 mm |
| Product Weight | 5.2kg |
