PRODUCT INFORMATION OF 1606-XLP90E-2 New American Rockwell AB PLC switching power supply.
| Height | 75 mm |
| Depth | 103 mm |
| Direct mounting possible | No |
| Width | 73 mm |
| Degree of protection (IP) | IP20 |
| Type of electric connection | Spring Clamp connection |
| Shock | 30 G, 6 ms 20G, 11 ms |
| Special functions | No special function |
| MTBF | 1594000 hours @ 40 °C, SN 29500 |
| Wall mounting possible | Yes |
| Degree of protection (NEMA) | Other |
| Vibration | 2 G |
| Secondary voltage adjustable | Yes |
| Power output | 90 W |
| Voltage type of supply voltage | AC |
| Efficiency, typ | 89.5 % |
| Adjustment range | 24 V |
| Operational range | 323…552V AC |
| Rated output current | 3.75 A @ 24V |
| Phases | 2-phase |
| Sub group | Compact family |
| Hold-up time | >93 ms @ 480V AC |
| Input voltage | 380…480V AC, 2-phase |
| Special family function | No power boost |
| Rated input current | <0.42 A @ 400V AC |
| Special feature | NEC Class 2 |
| Output voltage stabilized | Yes |
| Rail mounting possible | Yes |
| Stabilized | Yes |
