| Width |
106.68 cm |
| Height |
129.54 cm |
| Depth |
159.26 cm |
| Screw torque, alarm terminal |
0.56 Nm |
| Screw torque, ground terminal |
0.4 Nm |
| Screw torque, power terminal |
0.56 Nm |
| Number of ports 10/100/1000 Mbps RJ45 |
2 |
| Layer 2 |
No |
| Layer 3 |
No |
| Manageable |
No |
| Pulse (digital) output |
24 W |
| Power dissipation |
24 W |
| Encryption |
K9 encryption with VPN for SSL |
| Total number of ports |
4 |
| Wire size, alarm connection, solid or stranded, UL/CSA-rated style 1007 or 1569 twisted-pair copper appliance wiring material (AWM) wire |
0.8 mm² |
| Wire size, DC power connection, solid or stranded copper wire rated at 75 °C or greater |
0.8 mm² |
| Wire size, ethernet connection |
RJ45 connector according to IEC 60603-7, 2 or 4-pair category 5e minimum cable according to TIA 568-B.1 or category 5 cable according to ISO/IEC 24702 |
| Wire size, ground connection, solid or stranded copper wire |
4 mm² |
| Mounting method |
DIN rail (top hat rail) |
| Ethernet |
Yes |
| Protection type |
Alarm not rated |
| Wire insulation |
Copper |
| Insulation stripping length |
6.3±0.5 mm |
| Alarm relay at 30V DC |
1 A |
| Alarm relay at 48V DC |
0.5 A |
| Current rating, user supply at 12 – 48V DC, maximum |
2 A |
| Isolation voltage (continuous), basic insulation type, all ports to ground |
60 V |
| Maximum insulation, DC power connection |
1.2 mm |
| Number of ports 1GbE SFP |
2 |
| Wire strip length, alarm connection |
6.3±0.5 mm |
| Wire strip length, DC power connection |
6.3±0.5 mm |
| Wiring category on console ports |
3 |
| Wiring category on Ethernet ports |
2 |
| Wiring category on power and alarm ports |
2 |
