1794-IE8H American Rockwell AB ControlLogix PLC.
1794-IE8H American Rockwell AB ControlLogix PLC.1794 Series Model No: 1794-IE8H. The Allen-Bradley 1794-IE8H is a Flex I/O analog input module. It has Eight (8) Voltage / Current single-ended input channels. It receives analog signals such as 0-20 mA and 4-20 mA. It is compatible for use with Flex I/O communication adapters and installed to terminal bases such as 1794-TB3G or 1794-TB3GS.
Description
PRODUCT INFORMATION OF 1794-IE8H American Rockwell AB ControlLogix PLC.
| Manufacturer | Rockwell Automation |
| Wire Size: | Determined by installed terminal base |
| Mounting: | DIN Rail |
| External DC supply range: | 19.0 to 31.2V DC (includes 5% AC ripple) |
| External DC supply, nom: | 24V DC |
| Indicators: | 8 red fault indicators, 8 yellow channel indicators and 1 green for power. |
| Terminal base: | 1794-TB3G and 1794-TB3GS |
| Step Response to 99%: | 80 ms |
| Accuracy drift with temperature: | 0.05% Full Scale for 0 °C…55 °C (32…131 °F) |
| Absolute accuracy: | 0.1% Full Scale @ 20 °C (68°F) |
| No. of inputs: | Eight (8) Single Ended; non-isolated |
| Product Description: | Flex IO HART Module |
| Brand | Allen-Bradley |
| Conversion Type | Successive Approximation |
| Resolution | 16 bits |
| Part Number/Catalog No. | 1794-IE8H |
| Product Type | Flex I/O HART Analog Module |
| Inputs | 8 Single-ended |
| Data Format | Configurable |
| Functional Data Range | >17V @ 22mA |
| FlexBus Current External Input | 5V DC 80mA |
| Enclosure Type Rating | None (open-style) |
| Isolation Voltage | 50V Continuous |
| Power Dissipation | 3.9W @ 31.2V DC max. |
| Thermal Dissipation | 13.5 BTU/hr. @ 31.2V DC |
| UPC | 10612598323880 |
