| Number of digital inputs |
4 |
| Number of digital outputs |
4 |
| Digital inputs configurable |
No |
| Digital outputs configurable |
No |
| Type of voltage (input voltage) |
AC/DC |
| Type of output voltage |
DC |
| Type of digital output |
Transistor |
| Type of electric connection |
Screw connection |
| Status indicator |
8 yellow |
| On-state voltage, output |
24V DC nominal |
| On-state current, output |
Steady state: 0.5 A maximum |
| Number of I/O |
4 channel inputs/sink outputs combination |
| ON-state current, max |
5 mA |
| On-state current, nom |
3.0 mA @ 24V DC |
| Wire size |
0.2… 2.5 mm2 (24…12 AWG) solid or stranded copper wire rated @ 90 °C (194 °F), or greater, insulation maximum |
| Isolation voltage |
50V (continuous), basic insulation type, inputs to outputs, I/Os to backplane type tested for 60 s @ 720V DC, I/Os to backplane |
| Redundancy |
No |
| SIL according to IEC 61508 |
None |
| Power supply voltage |
10.8V DC, minimum, 30V DC, maximum |
