| Number of HW-interfaces industrial Ethernet |
1 |
| Number of HW-interfaces RS-232 |
1 |
| Number of HW-interfaces RS-422 |
1 |
| Number of HW-interfaces USB |
2 |
| Number of password levels |
2 |
| Voltage type of supply voltage |
DC |
| Number of online languages |
20 |
| Suitable for safety functions |
No |
| Supporting protocol for TCP/IP |
No |
| Supporting protocol for Modbus |
No |
| Supporting protocol for Data-Highway |
No |
| With colour display |
Yes |
| Number of pixels, vertical |
600 |
| With numeric keyboard |
No |
| With alpha numeric keyboard |
No |
| With message indication |
Yes |
| With message system (incl. buffer and confirmation) |
Yes |
| Process value representation (output) possible |
No |
| Process default value (input) possible |
No |
| With recipes |
No |
| With printer output |
Yes |
| Additional software components, loadable |
Yes |
| Supporting protocol for EtherNet/IP |
No |
| Screen diagonal |
12.1 inch |
| Number of pixels, horizontal |
800 |
| Useful project memory/user memory |
79000 MB |
| Supply voltage DC |
18 V |
| Touch technology |
Resistive touch |
| Display size |
12.1 inch |
| Luminance |
300 cd/m2 (Nits) |
| Operator input |
Touch |
| Power consumption |
70 W max (2.9 A at 24V DC), 39 W typical (1.6 A at 24V DC) |
| Display type |
Color active-matrix TFT |
| Memory |
512 MB RAM, 512 MB nonvolatile memory, (approx. 79 MB free user memory) |
| Touch screen |
8-wire analog resistive |
| Operating system |
Windows CE 6.0 operating system without extended features |
| Backlight |
CCFL, 50000 hours minimum at 25 ° C (77 °F) field replaceable |
| Recommended external power supply |
Cat. No. 1606-XLE120E, safety extra low voltage (SELV) or protected extra-low voltage (PELV) power supply for 700…1500 DC-powered terminals |
| Software |
FactoryTalk View Machine Edition software, version 6.0 or later, FactoryTalk ViewPoint software, version 1.2 or later |
| Input voltage |
24V DC nominal |
| Battery (real-time clock) |
Battery-backed clock timestamps critical data, accuracy is ±2 minutes per month |
| Communication ports |
Ethernet (10/100 Mbps, Auto-MDI/MDI-X), RS-232, (2) USB host, Network interface for optional Ethernet, DH+/DH-485, or ControlNet (scheduled or unscheduled) communication module |
| Supporting protocol for LON |
No |
| Supporting protocol for ASI |
No |
| Supporting protocol for PROFIBUS |
No |
| Supporting protocol for CAN |
No |
| Supporting protocol for INTERBUS |
No |
| Supporting protocol for KNX |
No |
| Supporting protocol for DeviceNet |
No |
| Supporting protocol for SUCONET |
No |
| Supporting protocol for other bus systems |
No |
| Supporting protocol for SERCOS |
No |
| Supporting protocol for INTERBUS-Safety |
No |
| Radio standard Bluetooth |
No |
| Radio standard Wi-Fi 802.11 |
No |
| IO link master |
No |
| Supporting protocol for AS-Interface Safety at Work |
No |
| Supporting protocol for DeviceNet Safety |
No |
| Supporting protocol for Foundation Fieldbus |
No |
| Supporting protocol for PROFINET CBA |
No |
| Supporting protocol for PROFINET IO |
No |
| Supporting protocol for PROFIsafe |
No |
| Supporting protocol for SafetyBUS p |
No |
| Radio standard GPRS |
No |
| Radio standard GSM |
No |
| Radio standard UMTS |
No |
| With SW interfaces |
Yes |
| Type of display |
TFT |
| Touch screen, operating force |
10 g |
| Special option |
Conformal-coated |
| Touch screen, actuation |
1 million presses |
| Battery life |
4 year minimum at 25 °C (77 °F) |
| Battery replacement |
Field-replaceable: cat. no. 2711P-RY2032 or equivalent CR2032 coin-cell lithium battery |
| External storage |
Secure Digital (SD) card, cat. no.1784-SDx, supported by hot-swappable SD card slot, USB flash drive that is supported by high-speed, hot-swappable, 2.0 USB host port |
