| Number of HW-interfaces industrial Ethernet |
1 |
| Number of HW-interfaces RS-232 |
1 |
| Number of HW-interfaces RS-422 |
0 |
| Number of HW-interfaces RS-485 |
0 |
| Number of HW-interfaces USB |
2 |
| Number of password levels |
2 |
| Number of grey-scales/blue-scales of display |
0 |
| Number of system buttons |
0 |
| Voltage type of supply voltage |
DC |
| Number of function buttons, programmable |
22 |
| Number of online languages |
20 |
| Suitable for safety functions |
Yes |
| Supporting protocol for TCP/IP |
Yes |
| Supporting protocol for Modbus |
No |
| Supporting protocol for Data-Highway |
Yes |
| With colour display |
Yes |
| Number of pixels, vertical |
480 |
| With numeric keyboard |
No |
| With alpha numeric keyboard |
Yes |
| With message indication |
Yes |
| With message system (incl. buffer and confirmation) |
Yes |
| Process value representation (output) possible |
Yes |
| Process default value (input) possible |
Yes |
| With recipes |
Yes |
| With printer output |
Yes |
| Additional software components, loadable |
No |
| Supporting protocol for EtherNet/IP |
Yes |
| Screen diagonal |
6.5 inch |
| Number of pixels, horizontal |
640 |
| Useful project memory/user memory |
79000 MB |
| Supply voltage DC |
18 V |
| Touch technology |
Resistive touch |
| Luminance |
300 cd/m² |
| Resolution |
640 x 480, 18-bit color graphics |
| Operator input |
Touch |
| Power consumption |
70 W max (2.9 A at 24V DC), 39 W typical (1.6 A at 24V DC) |
| Memory |
512 MB RAM, 512 MB nonvolatile memory, (approx. 79 MB free user memory) |
| Touch screen |
8-wire analog resistive, Actuation: 1 million presses, Operating force: 10…110 g |
| Operating system |
Windows CE 6.0 operating system without extended features |
| Backlight |
CCFL, 50000 hours minimum at 25 ° C (77 °F) field replaceable |
| Software |
FactoryTalk view machine edition software, version 6.0 or later, FactoryTalk ViewPoint software, version 1.2 or later |
| Input voltage |
18…30V DC (24V DC nominal), Requires the use of a Class 2 or safety extra low voltage (SELV) or protected extra-low voltage (PELV) power supply |
| Battery (real-time clock) |
Battery-backed clock timestamps critical data, accuracy is ±2 minutes per month, Battery life: 4 year min at 25 °C (77 °F), Field-replaceable: cat. no. 2711P-RY2032 or equivalent CR2032 coin-cell lithium battery |
| Communication ports |
Ethernet (10/100 Mbps, Auto-MDI/MDI-X), RS-232, (2) USB host, Network interface for optional Ethernet, DH+/DH-485, or ControlNet (scheduled or unscheduled) communication module |
