ABB single-phase current monitoring relay CM-SRS.11S, 220-240VAC, 10081167.

PRODUCT INFORMATION OF ABB single-phase current monitoring relay CM-SRS.11S, 220-240VAC, 10081167.

General Information

• Extended Product Type:

  CM-SRS.11S

• Product ID:

  1SVR730841R1200

• EAN:

  4016779852326

• Catalog Description:

  CM-SRS.11S Current monitoring relay 1c/o, B-C=3mA-1A RMS, 220-240VAC

• Long Description:

  The CM-SRS.11S is a single-functional current monitoring relay from the CM single-phase monitors range. This monitoring relay operates with a rated control supply voltage of 220 – 240 V AC and has a 1 c/o (SPDT) output contact rated at 250 V / 4 A. It provides a RMS measuring principle for DC and AC currents with 3 measuring ranges: 3-30 mA, 10-100 mA and 0.1-1 A and works according to the open-circuit principle. The CM-SRS.11S is configurable for over- or undercurrent monitoring, the hysteresis is adjustable within a range of 3 to 30 % of the threshold value. A sealable transparent cover for protection against unauthorized changes is available as accessory. The device offers screw connection technology with double-chamber cage connection terminals.

Classifications of ABB single-phase current monitoring relay

• Object Classification Code:

  B

• ETIM 4:

  EC001440 – Current monitoring relay

• ETIM 5:

  EC001440 – Current monitoring relay

• ETIM 6:

  EC001440 – Current monitoring relay

• ETIM 7:

  EC001440 – Current monitoring relay

• ETIM 8:

  EC001440 – Current monitoring relay

• eClass:

  V11.0 : 27371802

• UNSPSC:

  39121514
