ABB small universal intermediate relay head CR-MX110DC2T 10228999.

Description

PRODUCT INFORMATION OF ABB small universal intermediate relay head CR-MX110DC2T 10228999.

General Information of ABB small universal intermediate relay head

• Extended Product Type:

  CR-MX110DC2T

• Product ID:

  1SVR405641R8000

• EAN:

  4013614536038

• Catalog Description:

  CR-MX110DC2T Pluggable interface relay 2c/o, A1-A2=110VDC, 250V/7A, test button

• Long Description:

  The CR-MX110DC2T pluggable interface relay is from the CR-MX (miniature) relay range. This relay operates with a 110 V DC rated control supply voltage and has a 2 c/o (SPDT) output with contacts rated at 250 V /7 A. The relay has an integrated blue test button for manual actuation and locking of the output contacts. Standard sockets, pluggable function modules, holders and markers are available as accessories.

Classifications

• Object Classification Code:

  K

• ETIM 5:

  EC001437 – Switching relay

• ETIM 6:

  EC001437 – Switching relay

• ETIM 7:

  EC001437 – Switching relay

• ETIM 8:

  EC001437 – Switching relay

• eClass:

  V11.0 : 27371601

• UNSPSC:

  39122331
