Description
PRODUCT INFORMATION OF Omron CJ1W-NC233.
| Power supply voltage |
5 V DC (for the PCU itself) | ||
|---|---|---|---|
| 24 V DC (external power supply) | |||
| 5 V DC (external power supply; line driver output only) | |||
| Allowable power supply voltage range |
4.75 to 5.25 V DC (for the PCU itself) | ||
| 21.6 to 26.4 V DC (external power supply) | 22.8 to 25.2 V DC (external power supply) |
||
| 4.75 to 5.25 V DC (external power supply; line driver output only) | |||
| Internal current consumption |
250 mA max. at 5 V DC | 250 mA max. at 5 V DC | 360 mA max. at 5 V DC |
| Current consumption of external power supply |
NC113: 30 mA max. at 24 V DC NC133: 10 mA max. at 24 V DC NC133: 60 mA max. at 5 V DC |
NC213: 50 mA max. at 24 V DC NC233: 20 mA max. at 24 V DC NC233: 120 mA max. at 5 V DC |
NC413: 100 mA max. at 24 V DC NC433: 30 mA max. at 24 V DC NC433: 230 mA max. at 5 V DC |
| External dimensions |
90 (H) × 31 (W) × 65 (D) (all models) | ||
| Weight | 100 g max. | 100 g max. | 150 g max. |
| Ambient operating temperature |
0 to 55 ° C | 0 to 50 ° C * | |
