DELTA PLC DVS-008W00-M12

Description

PRODUCT INFORMATION OF DELTA PLC DVS-008W00-M12

Specifications

TECHNOLOGY

1. Processing Type
2. Store and Forward
3. IEEE 802.3x Flow control in full duplex, back-pressure flow control in half duplex

4. ---

INTERFACE

1. Fast Ethernet Ports
2. M12 Ports: D-coded 4-pin female connector, 10/100Base-T(X), auto MDI/MDI-X, auto negotiation

3. ---

PERFORMANCE AND SCALABILITY

1. Switching Capacity: 1.6Gbps, Wired speed, Non-blocking switching fabric
2. Forwarding Rate: 2.38Mpps
3. MAC Address Table: 2K
4. Packet Buffer Memory: 448K bits
5. Transparent Forwarding VLAN Tagged Packets: Default enabled

6. ---

POWER REQUIREMENTS

1. M12 Port: 1 A-coded 4-pin male connector
2. Input Voltage: 2 sets, 12 to 48 VDC redundant input
3. Input Current: 0.156A
4. Overload Current Protection: Present, max. input current 3A
5. Reverse Polarity Protection: Present

6. ---

PHYSICAL

1. Housing: IP67 metal case
2. Dimensions: 194 mm(H) x 62 mm(W) x 25 mm(D)
3. Weight: 355g
4. Installation: Industrial DIN-Rail and wall mounting

5. ---

ENVIRONMENTAL LIMITS

1. Operating Temperature: -40℃ to 75℃ (-40℉ to 167℉)
2. Storage Temperature: -40℃ to 85℃ (-40℉ to 185℉)
3. Ambient Relative Humidity: 5% to 95% (non-condensing)

4. ---

APPROVALS

1. Safety: UL 61010, EN 62368-1
2. EMI: FCC 47 CFR Part 15 Subpart B Class A, IEC 61000-6-4, EN 55032, EN 55011, AS/NZS CISPR 32
3. EMS(IEC 61000-6-2, EN55024): IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8
4. Shock: IEC 60068-2-27
5. Freefall: IEC 60068-2-32
6. Vibration: IEC 60068-2-6
7. Hi-Pot: 1.5KV
