Description
PRODUCT INFORMATION OF Omron fiber optic amplifier E3C-JC4P 2M reflection switch.
| Type | Photoelectric sensor amplifier |
| Power supply voltage | 12…24 VDC |
| Sensitivity setting | Adjuster |
| Output type | NPN |
| External inputs | Contact input |
| Operation mode | Dark ON, Light ON |
| Response time | 1 ms |
| Display type | LED indicator |
| Protection circuit | Output short-circuit protection, Output reverse polarity protection |
| Functions | Timer, Mutual interference prevention, Self diagnostic |
| Communications | No |
| Lens material | Plastic |
| Case material | Plastic |
| Mounting method | Bracket mounting |
| Connection method | Pre-wired |
| Cable length | 2 m |
| Operation ambience | Standard |
| Ambient temperature | -10…55°C |
| Ambient humidity | 35…85% RH |
| Approx. weight | 80 g |
| Overall width | 60 mm |
| Overall height | 32.5 mm |
| Overall depth | 14 mm |
| Degree of protection | IP40 |
| Representative standard | IEC |
| Standard accessories | Bracket |
| Separately accessories | No |
