| UPC Code |
4547648451925 |
| Type |
High Function 1/4 Din Option Output |
| Display Type |
Triple Line |
| Output Type |
2 Alarms or More, Alarm Output Relay, Remote Set point, Heater Alarm, 3-phase Heater Alarm, Event IP (1 or 2), Transfer Output |
| Input Type |
Thermocouple, Resistance Temperature Detector (RTD), Linear |
| Dependencies |
E53-RN, E53-QN, E53-Q3, E53-Q4, E53-C3N, E53-C3DN, E53-V34N, E53-E35N, E58-CIFIR, E58-CIFQ1, E53-AKB, E53-EN03 |
| Accessories |
EST2-2C-MV4, E58-CIFQ1, ES1B10-70C, ES1B115-165C, ES1B140-260C, E54-CT1, E54-CT3, NS-AL002, NT-AL001, CJ1W-CIF11 |
| Spare Parts |
E53-COV16, Y92S-P4 |
| Special Function |
Logic Function, Ramp/Soak, Advanced Temperature Controller |
| Size |
96 x 96 mm1/4 DIN |
| Main Control Output |
Selectable Via Output Boards |
| Control Function |
Heat and Cool |
| Communications |
USB (E58-CIFQ1), Option Units RS-232C (E53-EN01), RS-422 (E53-EN02), RS-485 (E53-EN03) |
| Protocol |
Serial, Modbus, PROFIBUS (via gateway), SYSWAY |
| IP Rating |
IP66 |
| Alarms |
3 Relays |
| Heater Burnout Detection |
Yes (Installed in controller) |
| Solid State Relay (SSR) Defect Detection |
Yes (Installed in controller) |
| Second Set Point |
Yes |
| Control Output 2 |
E53-R (Relay), E53-Q (Voltage)E53-Q3 (Voltage for SSR +24VDC (NPN), E53-Q4 (Voltage for SSR +24 VDC (PNP), E53-C3 (Current +4 to 20mA DC), E53-C3D (Current +0 to 20 mA DC), E53-V34 (Linear Voltage +0 to 10 VDC), E53-V35 (Linear Voltage +0 to 5 VDC) |
| Remote Set Point Input |
1 |
| Input Sampling Period |
60 ms |
| Ramp/Soak Cycle |
4 Simple Patterns |
| Control Method |
ON/OFF-control, 2 Proportional Integral Derivative (PID) Control |
| Operating Temperature [Min] |
700 ºC |
| Alternating Current (AC) Supply Voltage |
24 V |
| Direct Current (DC) Supply Voltage |
24 V |
| Transfer Output |
Yes |
| Event Inputs |
2 |
| Compatible HMI Series |
NS, NSJ |
| Setup Tools |
Smart Active Parts for NS/NSJ |
