Panasonic 4 horses 2CB067LA0M-R22 medium temperature refrigeration compressor
Panasonic 4 horses 2CB067LA0M-R22 medium temperature refrigeration Compressor Model Number: 2CB067LA0M. Panasonic compressor 2CB067LA0M is a 4-hp R22 medium-temperature refrigerated scroll compressor produced by Panasonic Compressor (Dalian) Co., Ltd., power supply voltage: 3φ, 380-415V/50Hz, 440-460V/60Hz, displacement is 66.7 (cm3 /rev), the cooling capacity at 50Hz is 7.75(kW), the input power is 2.86kW, the cooling capacity at 60Hz is 9.34kW, and the input power is 3.45kW
Description
PRODUCT INFORMATION OF DANFOSS Panasonic 4 horses 2CB067LA0M-R22 medium temperature refrigeration compressor
4p Panasonic compressor 2CB067LA0M medium temperature scroll refrigeration compressor
R22 Refrigerant Medium Temperature Model Use Standards and Use Limits:
Evaporating Temperature Range (Evaporating Temp): -15～+12℃
Condensing Temperature Range (Condensing Temp.): +15～+65℃
Compression Ratio: 1.8-6
Panasonic compressor 2CB067LA0M technical parameters specifications: cooling capacity, operating current, power, high and low pressure, etc.
Panasonic 4 hp R22 refrigerating compressor 2CB067LA0M Maintenance and replacement precautions: Refrigerant/fluorine/refrigerant model and charging amount, refrigerating lubricating oil model and adding amount, high and low pressure values, operating current values, suction and exhaust temperature range etc.
Comparison of Dalian Panasonic medium-temperature compressor 2CB067LA0M with similar Copeland compressors/Danfoss compressors/Inwalt compressors/Hitachi compressors used in the field of refrigeration in terms of performance and parameters.
