Proface GP-4201TW proface gp2500-tc41-24v
Proface GP-4201TW proface gp2500-tc41-24v Model Number: GP-4201TW. The GP-4201TW touchscreen is a Pro-face interface display unit from the company’s GP-4000 series. This unit has a TFT color LCD measuring 3.5 inches with 320 x 240-pixel resolution.
The GP-4201TW has a non-replaceable white LED backlight. This LED cannot be replaced by the user but has a lifetime use rating of 50K hours or more. The backlight is adjustable to eight brightness levels.
The GP-4201TW’s display offers 65,536 no-blink colors as well as 16,384 blink colors. There are multiple ports available, including an RS-232C serial port, an RS422/485 transmission port, and an Ethernet port. The unit also has two USB ports: a type-A and a type-B mini port. The unit also has a single SD slot.
The grounding interface for the GP-4201TW offers functional ground that has a resistance of 100Ω. This ground should use AWG 14 or thicker wire. When installed, the panel enclosure is equivalent to an IP65f, NEMA 4x/13 enclosure. The display can be used in locations with some pollutants (up to pollution degree 2)
Description
PRODUCT INFORMATION OF PROFACE GP-4201TW proface gp2500-tc41-24v
| Display Color | 65,536 Colors (No blink)/16,384 Colors (Blink) |
| Display Type | Wide TFT Type Color LCD |
| Features | Energy Efficient LED Display |
| Global Code | PFXGP4201TADW |
| Input Power | 24VDC |
| Language Fonts | Japanese, Korean, Traditional Chinese, Simplified Chinese, Thai, and Cyrillic |
| Manufacturer | Pro-face |
| Product Type | Human Machine Interface |
| Resolution | 320 x 240 QVGA |
| Screen Size | 3.5-Inch |
| Series | GP4000 |
| Software | GP-Pro Ex |
| Touchscreen Display Resolution | 320 x 240 QVGA |
| Weight | Less than 2 lbs. |
