PRODUCT INFORMATION OF Schneider 140DAI75300
| range of product | Modicon Quantum automation platform |
|---|---|
| product or component type | VAC discrete input modules |
| software name | Concept Unity Pro ProWORX 32 |
| discrete input number | 32 |
| group of channels | 4 |
| addressing requirement | 2 input words |
| discrete input voltage | 230 V AC |
| input current | 11.5 mA at 57…63 Hz 9.7 mA at 47…53 Hz |
| voltage state 1 guaranteed | 165…264 V AC at 57…63 Hz 175…264 V AC at 47…53 Hz |
| voltage state 0 guaranteed | 0…40 V AC at 57…63 Hz 0…40 V AC at 47…53 Hz |
| input impedance | 26500 Ohm capacitive at 57…63 Hz 31800 Ohm capacitive at 47…53 Hz |
| network frequency limits | 47…63 Hz |
| maximum leakage current | 2.6 mA |
| absolute maximum input | 264 V continuous 312 V 10 s 400 V 1 cycle |
| response time | 4.9…0.75 ms x line cycle Off-On 7.3…12.3 ms On-Off |
| isolation between group | 1780 Vrms for 1 minute |
| isolation between group and bus | 1780 Vrms for 1 minute |
| bus current requirement | 250 mA |
| maximum power dissipation in W | 5 W |
| local signalling | 1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault detected (F) 32 LEDs (green) for input status |
| Marking | CE |
| module format | Standard |
| Net weight | 0.3 kg |
| Standards | CSA C22.2 No 142 UL 508 |
| product certifications | FM Class 1 Division 2 cUL |
| resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2 8 kV on air conforming to IEC 801-2 |
| resistance to electromagnetic fields | 10 V/m 80…2000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 4.7 cm |
| Package 1 Width | 16.4 cm |
| Package 1 Length | 31.0 cm |
| Package 1 Weight | 513.5 g |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 7 |
| Package 2 Height | 30.0 cm |
| Package 2 Width | 30.0 cm |
| Package 2 Length | 40.0 cm |
| Package 2 Weight | 4.03 kg |
| Warranty | 18 months |
