TM3BCEIP plc module, TM3 series PLC module spot free shipping
TM3BCEIP plc module, TM3 series PLC module spot free shipping Uncategorized Model Number: TM3BCEIP This product is part of the Modicon TM3 range, an offer of expansion I/O modules for Modicon M221, M241, M251 and M262. The I/O distributed module supports daisy chain topology. It offers half duplex, full duplex and auto negotiation exchange mode with 10/100Mbps data transmission rate. This processor provides web services like web server, ethernet and web server, USB. It features 1 LED for PWR (system status), 1 LED for MS (module status), 1 LED for NS (network status) and 1 LED for I/O status signaling. It is an IP20 rated product. Its dimensions are 27mm (width) x 70mm (depth) x 96.5mm (height). It weighs 0.10kg. It is suitable for bus coupler module. It is compatible with logic controller and motion controller. Modicon TM3 expansion modules have been designed with a simple interlocking assembly mechanism. Boost the performance of controller with the Modicon TM3 I/O system specially designed for the Modicon M221, M241, M251 and M262 logic controllers. TM3BCEIP plc module
Description
PRODUCT INFORMATION OF SCHNEIDER TM3BCEIP plc module, TM3 series PLC module spot free shipping
| Range of product | Modicon TM3 |
|---|---|
| Product compatibility | Logic controller Motion controller |
| Product or component type | I/O distributed module |
| Product specific application | Bus coupler module |
| Communication port protocol | Ethernet IP/Modbus TCP |
| connector type | RJ45 2 Ethernet daisy chain isolated USB device port Mini-B |
| Exchange mode | Half duplex, full duplex, autonegotiation |
| Transmission rate | 10/100 Mbit/s |
| Topology | Daisy chain |
| Port Ethernet | 10/100BASE-T |
| Communication network type | Ethernet IP Modbus TCP IPv4 (internet protocol) |
| Communication service | Ethernet/IP adapter Modbus TCP/IP server RSTP (Ring topology support) SNMP Web server DHCP client BOOTP Address conflict detection FTP server |
| web services | Web server, Ethernet Web server, USB |
| current consumption | 0.8 A at 24 V DC internal supply maximum 7 expansion modules |
| local signalling | 1 LED green/red for PWR (System Status) 1 LED green/red for MS (Module Status) 1 LED green/red for NS (Network Status) 1 LED green/red for I/O status |
| fixing mode | By clipping locks (rail) By screws (mounting plate) |
| Width of TM3BCEIP plc module | 27 mm |
| Height of TM3BCEIP plc module | 96.5 mm |
| Depth of TM3BCEIP plc module | 70 mm |
| Product weight | 0.10 kg |
| Ambient air temperature for storage | -25…70 °C |
| Pollution degree | 2 |
| Ambient air temperature for operation | -10…60 °C |
| IP degree of protection | IP20 conforming to IEC/EN 61010-2-201 |
| relative humidity | 10…95 % non-condensing |
| Operating altitude | 0…2000 m |
| Storage altitude | 0…3000 m |
| vibration resistance | 3M4 on 35 x 15 mm symmetrical DIN rail |
