150-F317NBD Rockwell AB SMC Flex soft starter current 317A.
150-F317NBD Rockwell AB SMC Flex soft starter current 317A.Soft Start Series Model No: 150-F317NBD.The Allen-Bradley 150-F317NBD is a SMC Flex Smart Motor Controller. This motor controller has a line Voltage of 200-460VAC, 3-Phase, 50 and 60 Hz and control Voltage of 100-240V AC (5-480 A units). It delivers maximum continuous output current of 317 Amperes and output power of 250 HP at 460VAC rated voltage with an open type enclosure.
Description
PRODUCT INFORMATION OF 150-F317NBD Rockwell AB SMC Flex soft starter current 317A.
| Manufacturer | Rockwell Automation |
| Part Number/Catalog No. | 150-F317NBD |
| Protection and Diagnostics | Power loss, line fault, voltage unbalance, excessive starts/hour, phase reversal, undervoltage, overvoltage, controller temp, stall, jam, open gate, overload, underload, communication fault. |
| Metering | Amps, volts, kW, kWh, MW, MWH, elapsed time, power factor, motor thermal capacity usage |
| Auxiliary Contacts | Four fully programmable contacts as normal/up-to- speed/fault/alarm/network (N.O./N.C.), or external bypass (N.O. only) |
| Communications | One DPI provided for connection to optional human interface and one DPI provided for connection to communication |
| Maximum output Power | 250 HP |
| Maximum output Current | 317 A |
| Line Voltage: | 200…460V AC, 3-Phase, 50 and 60 Hz |
| Operating Modes: | Soft Start, Full Voltage Start, Smart Motor Braking, Current Limit Start, Dual Ramp Start, Accu-Stop, Selectable Kickstart, Pump Start, Slow Speed with Braking, Coast-to-rest, Preset Slow Speed, Linear Speed Acceleration (Tachometer required), Soft Stop and Pump Stop |
| Product Family: | SMC Flex Smart Motor Controller |
| Brand | Allen-Bradley |
| Bulletin Number | 150 |
| Control Voltage | 100…240V AC (5…480 A units) |
| Product Line | SMC-Flex |
| Module Type | Motor Controller |
| Enclosure Type | Open |
| Controller Rating | 317 A, 250 Hp at 460 Volts AC |
| Input Line Voltage | 200 to 460 Volts AC, 3-phase, 50 and 60 Hz |
| Rated Voltage | 200 to 460 Volts AC |
| Weight | 45.8 kilograms |
| Dimensions | 23.62 x 11.42 x 10.88 inches |
| Display | Integral LCD Display |
