1794-IA8 American Rockwell AB ControlLogix PLC.
1794-IA8 American Rockwell AB ControlLogix PLC.1794 Series Model No: 1794-IA8. The Allen-Bradley 1794-IA8 input module is a discrete input module with 8 inputs. It is part of the Flex I/O 1794 series. The 1794-IA8 input module is an AC-powered input module with a nominal voltage rating of 120 Volts AC. It is an open-style module with an IP 20 environmental protection rating that mounts on a DIN Rail. The 1794-IA8 input module?s 8 inputs are not isolated from each other.
Description
PRODUCT INFORMATION OF 1794-IA8 American Rockwell AB ControlLogix PLC.
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1794-IA8 |
| Product Type | Flex I/O AC Digital Input Module |
| Inputs | 8 Non-Isolated |
| On-state Voltage min. | 65V AC |
| On-state Voltage max. | 132V AC |
| On-state Current min. | 7.1mA |
| On-state Current max. | 14.32mA |
| Off-state Voltage max. | 43V AC |
| Off-state Current min. | 2.9mA |
| Nominal Input Current | 12 mA @ 120V AC |
| Flexbus Current | 30mA @ 5V DC |
| Power Dissipation | 4.5W @ 132V AC max. |
| UPC | 10612598137760 |
