1794-IM8 New American Rockwell AB ControlLogix FLEX I/O.
1794-IM8 New American Rockwell AB ControlLogix FLEX I/O.1794 Series Model No: 1794-IM8. The Allen-Bradley 1794-IM8 Flex I/O 220V AC Digital Input Module has 8 Nonisolated Inputs, a 240V AC On-state Voltage nom., and a 13.21 mA On-state Current max.. It also operates with a 2.6mA Off-state Current max. and a 22.3 k? Nominal Input Impedance.
Description
PRODUCT INFORMATION OF 1794-IM8 New American Rockwell AB ControlLogix FLEX I/O.
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1794-IM8 |
| Product Type | Flex I/O 220V AC Digital Input Module |
| Inputs | 8 Nonisolated |
| On-state Voltage nom. | 240V AC |
| On-state Current max. | 13.21 mA |
| Off-state Voltage max. | 40V AC |
| Off-state Current max. | 2.6mA |
| Nominal Input Impedance | 22.3 k? |
| Nominal Input Current | 12mA @ 240V AC |
| Isolation Voltage | 250V Continuous |
| Flexbus Current | 30mA @ 5V DC |
| Thermal Dissipation | 16.2 BTU/hr. @ 264V AC max. |
| UPC | 10612598179937 |
