1794-IT8 American Rockwell AB ControlLogix PLC.
1794-IT8 American Rockwell AB ControlLogix PLC.1794 Series Model No: 1794-IT8. The Allen-Bradley 1794-IT8 is a Flex I/O . This module is Thermocouple and millivolt input module that has Eight (8) channels compatible with Thermocouple sensors J, K, E, R, N, S, B, C, T and L sensors and accepts +/-76.5m voltage range. This module has 16-bit resolution and has a FlexBus current draw of 20 mA.
Description
PRODUCT INFORMATION OF 1794-IT8 American Rockwell AB ControlLogix PLC.
| Brand | Allen-Bradley |
| Keyswitch Position | 3 |
| Module Location: | 1794-TB2, -TB3 and -TB3T Terminal Base Units |
| CJC unit: | A-B Part Number 969424–0 |
| Indicator: | 1 red/green power status indicator |
| Data Format: | 16-bit 2’s complement or offset binary (unipolar) |
| millivolt signal: | +/- 76. 5mV |
| Sensors supported: | J, K, E, R, N, S, B, C, T and L |
| No. of Inputs: | 8 |
| Part Number: | 1794- IT8 |
| Product Family: | Flex I/O Modules |
| Manufacturer | Rockwell Automation / Allen-Bradley |
| Part Number/Catalog No. | 1794-IT8 |
| Product Type | Thermocouple / milivolt Input Module |
| Resolution | 16 bits (2.384 microvolts typical) |
| Power Dissipation | 3W maximum @ 31.2V |
| Inputs | 8 Channels |
| Nominal Input Ranges | -76.5 to 76.5 mV |
| Isolation Voltage | 850 Volts DC |
| Normal Mode Noise Rejection | -60db at 60 Hertz |
| Channel Bandwidth | 0 to 2.62 Hertz |
| Normal Mode System Throughput | 325 milliseconds |
| Flexbus Current | 20 mA |
| Thermal Dissipation | 10.2 BTU/hour at 31.2 Volts DC maximum |
| UPC | 10612598137838 |
