| Digital inputs configurable |
No |
| Digital outputs configurable |
No |
| Type of voltage (input voltage) |
DC |
| Type of output voltage |
DC |
| Type of digital output |
Transistor |
| Type of electric connection |
Screw connection |
| Status indicator |
4 yellow |
| Number of I/O |
4 (sink outputs) |
| ON-state current, max |
Steady state: 0.5 A, 2 A, surge for 2 s, minimum |
| Wire size |
0.2… 2.5 mm2 (24…12 AWG) solid or stranded copper wire rated @ 90 °C (194 °F), or greater, insulation maximum |
| Isolation voltage |
50V (continuous), basic insulation type, inputs to outputs, I/Os to backplane type tested for 60 s @ 720V DC, I/Os to backplane |
| Redundancy |
No |
| SIL according to IEC 61508 |
None |
| Power supply voltage |
10.8V DC, minimum, 30V DC, maximum |
| Surrounding air temperature, max |
65 °C |
| North American temperature code |
T4 |
| Relative humidity |
5…95% noncondensing |
| Operating temperature |
-20 to 65 °C |
| Nonoperating temperature |
40 to 85 °C |
| ON-state voltage, max |
30V DC |
| On-state voltage, min |
10V DC |
| On-state voltage, nom |
24V DC |
| On-state current, min |
5.0 mA @ 10V DC |
