Description
PRODUCT INFORMATION OF Keyence industrial static eliminator SJ-M020G.
| Model | SJ-M020G(1.2M) | |||
| Type | Head | |||
| Voltage application method | Pulse AC method | |||
| Applied voltage | ±5.5 kV | |||
| Rated output voltage | ±6 kV | |||
| Ion balance control method | I.C.C. method | |||
| Static elimination time | 0.5 sec max.*1 | |||
| Ion balance | ±15 V*2 | |||
| Air purge supplied pressure | 0.001 to 0.5 MPa*3 | |||
| Control input | Static elimination stop input | Non-voltage input | ||
| Control output | Alarm output | NPN open collector 100 mA (40 V or less) | ||
| Ion level alarm output | ||||
| Condition alarm output | ||||
| Rating | Power voltage | 24 VDC ±10 % | ||
| Current consumption | 450 mA or less | |||
| Environmental resistance | Ambient temperature | 0 to +80 °C*4*5 | ||
| Relative humidity | 35 to 65 % RH (No condensation)*3 | |||
| Weight | Approx. 540 g | |||
