PRODUCT INFORMATION OF OMRON safety door switch D4NS-1AF/D4NS-2AF/D4NS-4AF /D4NS-3AF
| Type | Tongue Interlock Switch |
| Contact Configuration | 1 Normally Closed (NC)/1 Normally Open (NO) |
| Conduit Size | Pg13.5 |
| Number of Conduit | 1 |
| Actuator Type | None |
| Actuation Speed (Operating Speed) [Max] | 500 mm/s |
| Conformity and Certifications | Machinery Directive, Low Voltage Directive, EN50047, EN 1088, EN 60204-1, GS-ET-15, EN 60947-5-1, UL 508, CSA C22.2 No.14, GB14048.5 |
| Dependencies | D4NSKEY, Need One Operating Key Per Switch |
| Head Material | Plastic |
| IP Rating | IP67 |
| Actuation Frequency [Max] | 30 OPM |
| Break Contact Force [Min] | 60 N13.5 lb |
| Weight | 96 g |
| Operating Temperature with No Icing [Min] | -30 ºC |
| Operating Temperature with No Icing [Max] | 70 ºC |
| M20-to-NPT Adapter Included | No |
