1794-IF2XOF2IXT Rockwell AB ControlLogix PLC module.
1794-IF2XOF2IXT Rockwell AB ControlLogix PLC module.1794 Series Model No: 1794-IF2XOF2IXT. The Allen-Bradley 1794-IF2XOF2IXT is a Flex I/O isolated analog input module. This module has Two (2) isolated analog inputs with 16-bit unipolar resolution and 15-bit bipolar resolution. It accepts 0-20 mA, 4-20 mA and +/- 20 mA current signals; +/-10VDC, 0-10VDC, +/- 5VDC and 0-5 VDC voltage signals. It also has Two (2) isolated analog output channels with 15-bit resolution that is able to deliver 0-20 mA and 4-20 mA and +/-10VDC, 0-10VDC, +/- 5VDC and 0-5 VDC. output signals. This module has FlexBus current draw of 50 mA and compatible with a variety of terminal bases such as 1794-TB2, 1794-TB3, 1794-TB3S, 1794-TB3T, 1794-TB3TS, and 1794-TBN.
Description
PRODUCT INFORMATION OF 1794-IF2XOF2IXT Rockwell AB ControlLogix PLC module.
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1794-IF2XOF2IXT |
| Module Type | Combination analog I/O module |
| Product Type | Flex XT I/O Isolated Input Analog Module |
| No. of I/Os | Two (2) analog input; Two (2) Analog output |
| Inputs | 2 Isolated |
| Resolution | 16 bits |
| Current input signals: | 0-20 mA, 4-20 mA and +/- 20 mA; |
| Conversion Type | Sigma Delta |
| Voltage input signals: | +/-10VDC, 0-10VDC, +/- 5VDC and 0-5 VDC; |
| Input Current Terminal | 4-20mA |
| Input resolution: | 16-bit (unipolar); 15-bit (bipolar) |
| Input Voltage Terminal | +/- 10V |
| Current output signals: | 0-20 mA and 4-20 mA; |
| FlexBus Current | 50mA |
| Voltage output signals: | +/-10VDC, 0-10VDC, +/- 5VDC and 0-5 VDC |
| FlexBus current draw: | 50 mA @ 5VDC |
| External DC Power Supply | 24V DC nom. |
| Isolation Voltage | 120V Continuous |
| Installation: | DIN Rail |
| Power Dissipation | 2.0W @ 31.2V DC max. |
| Conversion type: | Sigma-Delta |
| Thermal Dissipation | 6.8 BTU/hr. @ 31.2V DC max. |
| Data Format: | 2’s complement; 2’s complement %; binary; offset binary |
| UPC | 10612598171566 |
| UPC | 10612598592590 |
