1794-IJ2 American Rockwell AB ControlLogix PLC.
1794-IJ2 American Rockwell AB ControlLogix PLC.1794 Series Model No: 1794-IJ2. The Allen-Bradley 1794-IJ2 is a Flex I/O module. This module is a Frequency Input module that is part of the 1794 Flex I/O system. This module has Two (2) Channel high resolution frequency input with Two (2) inputs per channel specifically frequency and gate input channels. It accepts input frequency – 1-32 kHz w/sine wave; 1-32 kHz w/square wave input and input pulse width of 20 ?s.
Description
PRODUCT INFORMATION OF 1794-IJ2 American Rockwell AB ControlLogix PLC.
| Manufacturer | Rockwell Automation |
| Wire Size: | Determined by installed terminal base |
| Power Dissipation | 4.6W maximum at 31.2V DC |
| Mounting: | DIN Rail |
| FlexBus Current: | 30 mA at 5V DC |
| External DC supply range: | 19.0…31.2V DC (includes 5% AC ripple) |
| Terminal base: | 1794-TB3G or -TB3GS. |
| Output Voltage, Nom: | 24VDC |
| Output Voltage, min: | 10VDC |
| Input Pulse Width: | 20 ?s |
| Raw Frequency Value: | Maximum 32,767 or 3,276.7 (dependent on range) |
| No. of Outputs: | Two (2) 24VDC |
| No. of inputs: | Two (2); Frequency; Two (2) Frequency and gate per channel |
| Product Description: | Flex IO Frequency Input Module |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1794-IJ2 |
| Thermal Dissipation | Maximum 15.6 BTU/hr at 31.2V DC |
| Input Frequency | 1-32 kHz w/sine wave; 1-32 kHz w/square wave input |
| Product Type | Flex I/O 2 Input Frequency Module |
| Inputs | 2 per Channel |
| On-state Voltage min. | 10V |
| On-state Current nom. | 9.0mA |
| Outputs | 2 Isolated |
| Output Voltage nom. | 24V DC |
| Output Off-state Voltage max. | 31.2V DC |
| Output On-state Current | 1.0A per Channel max. |
| UPC | 10612598180216 |
